Small Water Well Drilling Rig

Product name 150m Small water well drilling rig
Drilling Depth 150m
Application Water Well Driling
Drilling way Impact with rotary
Keyword Water Drilliing Rig
Drill pipe diameter 50 mm
Drill pipe length 1.5 m
Hoisting height 2 m
Equipped capacitor 4 KW
Elevating power 2000 KG

Brand Name Blurbly
Usage Water Well Driling
Dimension(L*W*H) 90*90*245 cm
Mobility yes

Quantity:
Availability:





Inquire Add to Basket

Model:
HW-150
Brand:
Blurbly

Product Description

Product name	150m Small water well drilling rig
Equipped capacitor	4KW
Rig lifting force	2000 KG
Drill pipe diameter	50 mm
Drill pipe length	1.5 m
Drilling depth	150 m
Hoisting height	2 m
Weight	2000 KG
Dimension	9090245 cm

Advantages

1.One man can operate, auto water flow control function.
2.Double lift chains, with hydraulic oil radiator.
3.Drilling process is stable, no jamming or shaking.
4.Electric start, it can charge the battery automatically.
5.Thicked and strong water swivel, inlet water pipe can change direction, with the screw to fix the inlet water pipe to ensure
there is no water leak.

6.Hydraulic oil radiator installed at the top near the hydraulic tank, it can cool the hydraulic oil well, also can prevent accidental collision (if installed below, it is easily crushed during transportation).
